This installation instructions will show you how to install the a electric tail gate lift system for Mercedes C Class W205, so we can open the trunk automatically and smoothly via a button or key.
Product link: Mercedes Benz Electric Tail Gate Lift, Hand-free Access Trunk
1, Diagram for reference
2, Remove the plastic buckle(position as picture show) and take out the decoration board
3, Remove the plastic buckle(position as picture show) and take out the decoration board
4, Pull out this plastic board
5, Take out the storage box
6, Find the harness of yellow socket from rear trunk computer board, product red signal cable connects to brown red cable, product yellow signal cable connects to brown cable
7, Remove the buckle as the red arrow and circle show and take out the right side decoration board, pull out the small light socket
8, Remove the spring on right side of trunk
9, Remove the spring buckle and install the front bracket
10, Install the rear bracket
11, Install the product pole
12, Spacer fixed on original buckle, use small drill to fix the it to the position as arrow show, then use 9.5 twist drill to expand hole
13, Install the product suction lock then fix the cord
14, Suction motor fix to this position
Note: After installation, need to close and open the trunk manually one time then the auto trunk will start to work.
Remote Key instructions:
Open: long press trunk button on key
Close: short press trunk button on key
Driver cabin button instructions:
Open: pull the trunk button in cabin one time
Close: pull the trunk button in cabin one time
